RIMPulse Mobile ECG Device is an AI-based device and system that allows remote monitoring of patients' cardiac health. It is a non-invasive, wearable device that captures patients’ several vital data and transmits it wirelessly to a remote monitoring center or offline to mobile devices using Bluetooth, where it can be analyzed by medical staff.
It can be used in ambulance, remote clinics, airplans, ships and home care under medical expert's supervision.
RIMPulse Mobile ECG device
Parameters measured by RIMPulse solution:
- ECG (5 and 12 leads)
- Heart Rate
- Skin Temperature
- Respiratory Rate
- Fall detection
- SpO2
- Photoplethysmograph (PPG)
- Pulse Index
- Cuff-less blood pressure using a Machine Learning algorithm
Specifications
- Product description: Digital ECG device and skin thermistor
- Lead Wires: 5, 12 and 12 with skin temperature
- ECG Sampling rate: 500 sample/second
- ECG Resolution: 24-bit streaming
- Recording: Full disclosure
- Connectivity: Wi-Fi, Bluetooth and USB
- Models: 1 and 2
- Display: Computer screen, Android mobile phone and HealthIntact server.
- Dimensions : 117 x 25 x 72 mm
- Weight: 250 grams
- Number of channels: 7, 12 channels
-
Power :
- Rechargeable internal lithium battery
- Charger: USB charger
-
Battery Operation:
- Charging time: 3 hours
- Minimum operating time:
- 16 hours: using Bluetooth or USB or Wi-Fi mode.
- 24 hours: using only Holter Mode
- Storage : 30 days full disclosure
- Event button : yes
- Arrhythmia auto detection: tachycardia, bradycardia, pause, leads off, baseline (arrest), dropped beats, low battery and other alarms.
- Memory : 32 GB embedded micro SD card
- SD card recording time: 30 days
- Controls : integrated buttons
- Conformity: CE Mark
