RIMPulse Mobile ECG device


7-12 leads ECG device that can send all ECG signals and Skin Temperature to Health Intact cloud server near real time through internal Wi-Fi or send it to mobile phone through Bluetooth and then mobile can send all these data near real time to Health Intact cloud server through 3G or Wi-Fi with smart real-time analysis module on the mobile phone.

It can be used in ambulance, remote clinics, airplans, ships and home care under medical expert's supervision.

CE Mark 0297

Specifications

  • Product description: Digital ECG device and skin thermistor
  • Lead Wires: 5, 12 and 12 with skin temperature
  • ECG Sampling rate: 500 sample/second
  • ECG Resolution: 24-bit streaming
  • Recording: Full disclosure
  • Connectivity: Wi-Fi, Bluetooth and USB
  • Models: 1 and 2
  • Display: Computer screen, Android mobile phone and HealthIntact server.
  • Dimensions : 117 x 25 x 72 mm
  • Weight: 250 grams
  • Number of channels: 7, 12 channels
  • Power :
    • Rechargeable internal lithium battery
    • Charger: USB charger
  • Battery Operation:
    • Charging time: 3 hours
    • Minimum operating time:
      • 16 hours: using Bluetooth or USB or Wi-Fi mode.
      • 24 hours: using only Holter Mode
  • Storage : 30 days full disclosure
  • Event button : yes
  • Arrhythmia auto detection: tachycardia, bradycardia, pause, leads off, baseline (arrest), dropped beats, low battery and other alarms.
  • Memory : 32 GB embedded micro SD card
  • SD card recording time: 30 days
  • Controls : integrated buttons

  • Conformity: CE Mark
